Phased Array II

Register by calling 617-378-2067
Course Number: 103-PA40-WK2
Title: Phased Array II - Week 2 of 2
Duration: 5 day course, 40 hours total
Dates: On demand - Contact us to scheduled
Cost: $1,500

Prerequisites: Phased Array I Course and UT Level II
Format: Classroom PP with live Phased Array technology demonstrations
Class Size: 4 to 8 students per class
Audience: UT Shear Wave Technicians

Week 2 for UT Shear Wave Technicians

This course is primarily a laboratory-based class which focusses on scan plans, instrument calibrations, acquiring data, evaluating data, and reporting on your results. It reviews advanced ultrasonic concepts that are outlined in ASNT CP105 which are critical for understanding and performing code compliant Phased Array inspections.

Learn how to:
  • Use UT Phased Array method to perform UT in Lieu of X-ray per ASME Section V, Article 4 code
  • Generate Scan Plans for single and multiple groups
  • Perform Calibrations for Sensitivity, Wedge delay, TCG, and Encoders
  • Check proper probe function, setup and perform manual linear scans and manual sector scans
  • Create Multiple Groups for Semi-Automated weld inspection using various linear scans and/or sector scans
  • Analyse your data, characterize indications, and report your findings
Students who complete this course will have successfully logged 80 hours of UT training which is required to achieve ASNT level II certification in the Phased Array method.

Successful completion of this course will prepare a student to take an ASNT Phased Array method, Level II, Specific and Practical Exam.

Course Outline

Day 1
Generate Scan Plans using ES Beam Tool and ONDT Setup Builder
Understand proper weld and HAZ UT beam coverage

Day 2
Perform Phased Array Probe Checks for acceptable use
Perform Phased Array Sensitivity, Wedge delay, TCG, and Encoder Calibrations

Day 3
Perform Single Probe, Single Group, Manual scans on Plate and Welds
Setup Zero degree Linear Scans, Refracted L-wave, and Refracted S-wave Sector Scans

Day 4
Perform Multiple Group Semi-Automated scans on Welds
Refracted S-wave Sector Scans

Day 5
Data Evaluation, Flaw Characterization, and Flaw Sizing
Reporting of data per given code and acceptance criteria
Take a typical Phased Array SPECIFIC EXAM
